Copper-coated step index multimode optical fibers
(High OH)
Copper-coated step index multimode optical fibers have all the benefits of silica-silica fibers. Additional significant improvements include increased mechanical strength and greater fatigue resistance compared to non-hermetic and polymer-clad fibers (PCS). Their transmittance covers a spectral range of 250 to 1200 nm, and also remains stable in corrosive chemicals that normally react to silica glass. The temperature range is from -196C to +600C . Hermetically metal-coated optical fibers are the optimum candidate when used in high vacuum and harsh environmental conditions

FEUTURES:

  • Greatly enhanced resistance to high power laser radiation.
  • Higher core-to-clad ratio and enlarged NA optimized for coupling to high-energy lasers.
  • Better fiber cooling due to the heat-conducting metal coating.
  • Excellent mechanical strength and flexibility compared to polymer coated fibers.
  • The metal coating can be soldered and will not outgas.



Copper-coated step index multimode silica fibers ОКM-105/125Cu ОКM-110/125Cu ОКM-200/220Cu ОКM-300/330Cu ОКM-400/440Cu ОКM-600/660Cu ОКM-800/880Cu
Mode type MM MM MM MM MM MM MM
Index profile Step Step Step Step Step Step Step
Core diameter, µm 105 ± 2 113 ± 2 200 ± 2 300 ± 4 400 ± 5 600 ± 8 800 ± 10
Clad diameter, µm 125 ± 2 125 ± 2 220 ± 2 330 ± 4 440 ± 5 660 ± 8 880 ± 10
Coating diameter, µm 160 ± 10 160 ± 10 280 ± 10 420 ± 10 545 ± 10 775 ± 10 980 ± 10
Cladding offset, % < 2
Coating offset, % < 5
Attenuation at 800/1300 nm 1, dB/km (See grapf High OH) the loss spectrum in the long wavelength region ( > 1um) is higher than that of the material the loss spectrum is close to the material loss spectrum
Wavelength range, nm (See grapf High OH) 250 - 1100 250 - 1200
Coating material Copper 99,99%
Core material Pure syntetic silica (High OH)
Clad material Doped silica (F-doped)
Additional inner layer Carbon
Numerical Aperture (NA) 0.22 ± 0.02
Short-term bending radius 60 times the fiber diameters
Long-term bending radius 120 times the fiber diameters
Proof test, kpsi 100
Min operating temperature 2,3, C -196
Max operating temperature (short tume < 60s)2, C 600
Max operating temperature (long tume > 60s) 2, C < 400
Permissible rate of temperature change in the temperature range, C/min 5
1- under normal climatic conditions
2- in inert environment
3- at the minimum operating temperature, the integrity of the optical fiber is guaranteed
